2016 Mach 429 Trail

OK I have a sickness….there I said it, not sure why I ‘needed’ to get another bike, but riding the Pivot in Colorado just felt so great as did the Santa Cruz!  I rented the Mach 5.5 and fell in love but that bike was a little out of my price range. Fast forward a few seasons of riding(here that’s fall, winter, spring, winter more winter, and summer) and I find this nice, barely used Mach 429 and at a really great price!  Geometry was very close to the 5.5 and it can use either 29″ or 27.5+” wheels! I am not a huge fan of Sram drive trains but for the price, I’d give it a go!

The Sram GX shifters and X1 rear derailleur seem to be comparable to Shimano’s XT, which is what I usually prefer.  We’ll see if it’s worth a changeover once I get some miles on it!

The rest of this post is some initial stock copy/paste on the 2016 specs and some photos from the previous owner.  I cannot wait to get this on the trail and see how it compares to the Santa Cruz 5010!

Original Owner Comments:
If I had to guess I would say there are less than 150 miles on it total.

The handlebar, headset, and wheels are brand new off of another build.

Components include:
Brand: Pivot
Model: 429 Trail
Size: Medium
Year: 2016
Frame: Full Carbon 429 Trail, External housing, Boost 148,  Internal Dropper Routing
Rear Shock: Fox Float DPS
Fork: Fox 34 Performance 110×15 Boost
Front Travel: 130mm
Rear Travel: 116mm
SRAM X01 derailleur (11 speed)
SRAM GX shifter
FSA headset (No. 5.1)
RaceFace Turbine R Handlebar (Alloy 780mm) 20* rise
WTB saddle
Crankset: Race Face RIDE(175mm)
RaceFace Narrow Wide Chain Ring (32T)
Bottom Bracket: PF92
Cassette: SRAM XG1150 10-42
Chain: KMC X11L
Brakeset: SRAM Guide R 180F/160R
Handlebars: Race Face RIDE Riser 740mm
Wheelset: Sun Ringle Comp 29er
Front Hub: Sunringle Charger Comp 29 15x110mm
Rear Hub: Sunringle Charger Comp 29 Boost 12x148mm
Fox Transfer Dropper Post (125mm)
Tires:



Geometry Chart

Mach 429 Trail 29

S M L XL
A Seat Tube Length (C-T) 16.00 17.50 19.00 20.50
B Top Tube Length 22.85 23.90 24.75 25.60
C Head Tube Length 4.00 4.00 4.70 5.90
D Head Tube Angle 67.50° 67.50° 67.50° 67.50°
E Seat Tube Angle 72.80° 72.80° 72.80° 72.80°
F Chain Stay Length 17.45 17.45 17.45 17.45
G Bottom Bracket Height 13.19 13.19 13.19 13.19
H Standover Height 28.54 28.98 29.29 30.04
I Wheelbase 43.70 44.69 45.47 46.46
Stack 23.91 23.93 24.59 25.71
Reach 15.10 16.11 16.66 17.14

Mach 429 Trail 27.5+ w/17mm cup

S M L XL
A Seat Tube Length (C-T) 16.00 17.50 19.00 20.50
B Top Tube Length 22.85 23.90 24.75 25.60
C Head Tube Length 4.00 4.00 4.70 5.90
D Head Tube Angle 67.00° 67.00° 67.00° 67.00°
E Seat Tube Angle 72.30° 72.30° 72.30° 72.30°
F Chain Stay Length 17.45 17.45 17.45 17.45
G Bottom Bracket Height 13.08 13.08 13.08 13.08
H Standover Height 28.43 28.87 29.18 29.93
I Wheelbase 43.87 44.86 45.64 46.63
Stack 24.05 24.08 24.75 25.87
Reach 14.87 15.88 16.43 16.90



The frame looks clean and can’t find any major scratches!







Factory Specs

30.9mm seatpost.

34.9mm or 35mm (as some manufacturers call it) seat post clamp.

ZS (zero stack) 44mm top and (zero stack) 56mm bottom, or a Chris King Inset 2.

Will fit 27.5+ tires in 2.8″ (WTB) with up to 40mm (inner) rims.

Will clear either a 160mm or 180mm rotor.

Boost 148mm X 12mm hub/wheel spacing.

https://vimeo.com/pivotcycles/sag

Pivot-Suspension-Setup-2017.10.03

Press Fit 92 Bottom Bracket (sometimes called PF92 or BB92) design



This is a scratch on the bluish protective tape that comes on it from factory, hasn’t even been removed yet, that’s good!



Review from MBA 2015
